SKU: SCS-ESC8000-G4

ASUS ESC8000 G4

GPU server for tricky calculations
Manufacturer:
Asus
1
Specifications
  • 4U high-density GPU server
  • Patented design
  • Efficient cooling with redundant fans
  • Easy maintenance and management

The four height units occupying GPU server from ASUS works with two Intel Xeon processors and can be equipped with up to 3 terabytes of RAM. The eight front-accessible drive bays are unceremoniously docked to the SATA controller. Optionally, there is also a controller for fast SAS disks and SSDs. In addition, the ESC8000 G4 also offers two M.2 interfaces for SSDs (SATA 6 Gbit/s & PCIe Gen3 x4 link 22110/2280/2260), as well as two NVMe slots. (If the latter are used, the number of usable SATA drives is reduced from eight to six). Of its ten PCIe expansion slots, up to eight bays can be used for GPU cards. NVIDIA Tesla V100s are suitable for this, for example. Fully equipped, the fast computing machine achieves around 112 teraflops (Floating Point Operations Per Second) according to Single Precision calculations. For comparison: A server without GPU support calculates floating point operations about 200 times slower.


Similar products
GPU Server
ASUS ESC4000 G4
GPU server for tricky calculations
Show product
GPU Server
ASUS ESC8000 G4
GPU server for tricky calculations
Show product
Specifications
Dimensions and Weight
Width
439 Millimeter (mm)
Depth
798 Millimeter (mm)
Height
176 Millimeter (mm)
Weight
32 Kilogram (kg)
FormFactor
4 HE Rackmount
Administration
Dedicated Management Port
Yes
Management Controller
Aspeed AST2500
General
PCIe Generation
3.0
Model
ESC8000 G4
Manufacturer
Asus
Drive bays
2.5" compatible
No
Drive bays 2.5" (hotswap)
8
Expansion and connectivity
PCIe Slots total (CPU1/CPU2)
5/6
PCIe x8 Slots (CPU1/CPU2)
0/1
PCIe x16 Slots (CPU1/CPU2)
5/5
USB 2.0 Ports (front/rear/internal)
2/0/0
USB 3.0 Ports (front/rear/internal)
2/0/0
Processor
Processor Manufacturer
Intel
Processors (max.)
2
Processor socket
LGA-3647 (Socket P)
Rack mount rails
Quick release rails
No
Rail type
Teleskopschienen
Power supply
installed
3
80PLUS certification
Platinum
Required voltage
Wechselstrom 110/230 V (50/60 Hz)
Power supply
2200W Netzteil
Operating Environment
Operating Temperature (min.)
10 Celsius (°C)
Operating Temperature (max.)
35 Celsius (°C)
Memory
Memory modules (type)
LRDIMM
RDIMM
Memory channels per CPU
6
Warranty and service
Optional services
3 years onsite service (24/7)
3 years onsite service (NBD)
3 years advance exchange
5 years full service package BASIC from date of purchase
5 years onsite service (24/7)
5 years onsite service (NBD)
5 years advance exchange
Other services
Customer defined BIOS configuration
Customer defined drive partitioning
Customer defined system configuration
Customer image pre-installation
Service package
3 years full service package BASICfrom date of purchase
Enclosure backplane
Backplane (bandwidth)
12Gbit/s SAS
Backplane (Type)
Multilane
Backplane (Conntector)
2x SFF-8643
GPU
GPUs (max.)
8
Graphics
Graphics (type)
Aspeed AST2500 (64MB VRAM)
Mass storage controller
Mass storage controller (type)
Intel® C621
Mass storage controller (interface)
8x SATA3
Mass storage controller (bandwidth)
6 Gbit/s
Mass storage controller (supported RAID level)
Intel® RST (RAID 0,1,5,10 Windows only)
Network
# networking ports
2x
Networking (type)
Gigabit Ethernet
Networking controller
Intel® i350AM2
Plug type
RJ45
Software
Operating Systems (certified)
VMware vSphere 6.5 and above
Windows Server 2016
Windows Server 2019
