ASUS ESC8000 G4 - Starline Computer: Storage und Server Lösungen von erfahrenen Experten
/ / ASUS ESC8000 G4
66aa172718582157551253.png 66aa172718cc4149973724.png 66aa1727193f4876728385.png
SKU: SCS-ESC8000A-E12

ASUS ESC8000 G4

GPU server for tricky calculations
Manufacturer:
Asus
1
Specifications
  • 4U high-density GPU server
  • Patented design
  • Efficient cooling with redundant fans
  • Easy maintenance and management

The four height units occupying GPU server from ASUS works with two Intel Xeon processors and can be equipped with up to 3 terabytes of RAM. The eight front-accessible drive bays are unceremoniously docked to the SATA controller. Optionally, there is also a controller for fast SAS disks and SSDs. In addition, the ESC8000 G4 also offers two M.2 interfaces for SSDs (SATA 6 Gbit/s & PCIe Gen3 x4 link 22110/2280/2260), as well as two NVMe slots. (If the latter are used, the number of usable SATA drives is reduced from eight to six). Of its ten PCIe expansion slots, up to eight bays can be used for GPU cards. NVIDIA Tesla V100s are suitable for this, for example. Fully equipped, the fast computing machine achieves around 112 teraflops (Floating Point Operations Per Second) according to Single Precision calculations. For comparison: A server without GPU support calculates floating point operations about 200 times slower.


Similar products
GPU Server
ASUS ESC4000 G4
GPU server for tricky calculations
Show product
GPU Server
ASUS ESC8000 G4
GPU server for tricky calculations
Show product
Specifications
Dimensions and Weight
Width
440 Millimeter (mm)
Depth
800 Millimeter (mm)
Height
174.5 Millimeter (mm)
Weight
27 Kilogram (kg)
FormFactor
4 HE Rackmount
Administration
Dedicated Management Port
Yes
Management Controller
Aspeed AST2600
General
PCIe Generation
5.0
Model
ESC8000A-E12
Manufacturer
Asus
Drive bays
2.5" compatible
Yes
Drive bays 2.5" (hotswap)
8
Drive bays 3.5" (hotswap)
8
Expansion and connectivity
PCIe Slots total (CPU1/CPU2)
11
PCIe x8 Slots (CPU1/CPU2)
2
PCIe x16 Slots (CPU1/CPU2)
9
USB 2.0 Ports (front/rear/internal)
2/0/0
USB 3.0 Ports (front/rear/internal)
2/0/0
Processor
Processor Manufacturer
AMD
Processors (max.)
2
Processor socket
LGA 6096
Processor type
AMD EPYC™ 9004 (Genoa) processor
Rack mount rails
Quick release rails
No
Rail type
Teleskopschienen
Power supply
installed
3
80PLUS certification
Titanium
Required voltage
Wechselstrom 110/230 V (50/60 Hz)
Power supply
3000W Netzteil
Operating Environment
Operating Temperature (min.)
10 Celsius (°C)
Operating Temperature (max.)
35 Celsius (°C)
Memory
Memory modules (type)
LRDIMM
RDIMM
Memory channels per CPU
12
Memory capacity (fully populated)
6TB
Memory modules (max.)
24
Warranty and service
Optional services
3 Jahre Vorabaustausch-Service
5 Jahre Vorabaustausch-Service
3 Jahre Vor-Ort-Service NBD
5 Jahre Vor-Ort-Service NBD
3 Jahre Vor-Ort-Service 24/7
5 Jahre Vor-Ort-Service 24/7
Vollwartungsvertrag BASIC für 5 Jahre ab Lieferung
Other services
BIOS-Konfiguration nach Kundenwunsch
Festplattenpartitionierung nach Kundenwunsch
Individuelle Systemkonfiguration
Kundenimage Vorinstallation
Service package
3 years full service package BASICfrom date of purchase
Enclosure backplane
Backplane (bandwidth)
12Gbit/s SAS
Backplane (Type)
Hybrid
Backplane (Conntector)
2x SFF-8643
4x MCIO
GPU
GPUs (max.)
8
Graphics
Graphics (type)
Aspeed AST2600
Mass storage controller
Mass storage controller (type)
System on Chip
Mass storage controller (interface)
8x SATA3
Mass storage controller (bandwidth)
6 Gbit/s
Mass storage controller (supported RAID level)
Intel® RST (RAID 0,1,5,10 Windows only)
Network
# networking ports
2x
Networking (type)
10 Gigabit Ethernet
Networking controller
Intel X710-AT2
Plug type
RJ45
Software
Operating Systems (certified)
Windows Server 2019
Windows Server 2022
VMware vSphere 8.0
